This page contains a selection of example workcells and pre-planned projects you can use to evaluate Verbotics Weld.

Ready-to-run projects Workcells

Ready-to-run projects

Welds in these projects have already been identified and planned. Download a project and its workcell, open them in your Verbotics Weld trial, and simulate straight away.

ABB robot welding a pipe assembly on a 2-axis positioner
Pipe assembly

ABB Robotics FlexArc®

A pipe assembly with pipe-to-pipe joins and flanges.

Project Workcell
ABB robot welding a plate assembly on a 2-axis positioner
Plate assembly

ABB Robotics FlexArc®

A fabricated plate assembly, welded on a 2-axis positioner.

Project Workcell
Two ABB robots welding a trailer frame on a headstock-tailstock positioner
Trailer

ABB Robotics Dual with Rotator

A trailer frame constructed of RHS sections, welded by two robots.

Project Workcell
FANUC robot on a large gantry welding a ship panel
Ship panel

FANUC Large Gantry

A shipbuilding panel with stiffeners, welded by a gantry-mounted robot.

Project Workcell
FANUC CRX cobot welding a small plate assembly on a fixture table
Small plate assembly

FANUC CRX-10iA/L on Table

A small stiffened plate on a fixture table, welded by a FANUC CRX cobot.

Project Workcell
Universal Robots cobot welding a small plate assembly on a fixture table
Small plate assembly

Universal Robots UR10e on Table

A small stiffened plate on a fixture table, welded by a cobot.

Project Workcell
Track-mounted Yaskawa robot welding a fire pit held by a skyhook positioner
Fire pit

Yaskawa Motoman with Skyhook

A fire pit fabricated from plate, welded by a robot with a skyhook positioner.

Project Workcell
Track-mounted Yaskawa robot welding a plate assembly on a skyhook positioner
Plate assembly

Yaskawa Motoman with Skyhook

A fabricated plate assembly, welded by a robot with a skyhook positioner.

Project Workcell

Workcells

Use one of our example cells to plan your own parts. Download a workcell directly in Verbotics Weld when you create a New Project, or use the links below. Want your own cell modelled? Contact us.

Two track-mounted ABB robots with a shared rotator
ABB Robotics Dual with Rotator

A dual-robot workcell with two ABB IRB2600IDs with a shared 1-axis rotator.

Used in: Trailer

ABB FlexArc welding cell with guarding and a 2-axis positioner
ABB Robotics FlexArc®

Based on an ABB FlexArc® cell with an IRB2600ID robot and a 2-axis IRBP750B positioner.

Used in: Pipe assembly, Plate assembly

FANUC CRX cobot mounted on a welding table
FANUC CRX-10iA/L on Table

A FANUC CRX mounted on a table.

Used in: Small plate assembly

FANUC robot on a large pillar gantry
FANUC Large Gantry

A FANUC ArcMate on a 28m Admex pillar gantry.

Used in: Ship panel

Track-mounted OTC DAIHEN robot with a rotator and fixed workstation
OTC DAIHEN with Rotator

An OTC FD-V25L robot with a 1D laser sensor on a track, with a rotator and fixed workstation.

Download
Universal Robots UR10e cobot mounted on a welding table
Universal Robots UR10e on Table

A Universal Robots cobot on a fixture table.

Used in: Small plate assembly

Track-mounted Yaskawa Motoman robot with a headstock-tailstock rotator
Yaskawa Motoman with Positioner

A Yaskawa Motoman AR3120 on a 12m track, with a rotator and tailstock.

Download
Track-mounted Yaskawa Motoman robot with a skyhook positioner
Yaskawa Motoman with Skyhook

A track-mounted Yaskawa robot with a skyhook positioner.

Used in: Fire pit, Plate assembly
